| Brand KDF210 Optimat |
|
|
|
| Manufacturer: |
Brandt |
| Type: |
KDF 210 |
| Year |
2014 |
| Machine number: |
0-261- 20-7902 |
| Control: |
Easy Control 10+ with touchless positioning, Start-Stop optic-induct Sensors and LCD Display |
| Control panel: |
LCD, with 4 lines tekst, ergonomical positioned at infeed -side machine |
| YouTube: |
https://youtu.be/ZAKSfLvNzQg |
|
|
| Spindels: |
|
| Conveyor: |
Central transport conveyor chain greasing. |
| Top pressure-guifdance rolls: |
Handwheel setting with Siko-counter, rolls in 2 lines and posisioned |
| Pre-Milling: |
2 * 0.75 kW 200 Hz Incl. tools manual positioning (Siko counters), max. 3 mm overwidth band and max 40 mm product thickness tools manual positioning (Siko counters), max. 3 mm overwidth band and max 40 mm product thickness |
| Glue aggregate: |
A3 Glue aggregate for hotmelt and possibility to work PU melt, glue application roll underneath product, in reverse or in line turning, enforced band clipping knive |
| Pressure zone: |
1. side pressure roll drive and 2 free running pressure rolls to ensure good gluing |
| Cut saw: |
2 * 0.18 KWW, 12.000 tpm |
| Top & bottom trimming: |
2 * 0,27 KW reversed turning, 3 pre-set positions, straight, phase, round, max 3 mm band |
| Profile scraping units: |
Quick toolchange, edge thickness: max. 3 mm |
| Glue scraping: |
Turning knives |
|
|
| Chain width |
80 mm |
| Edge material thickness: |
min. 0.3 mm / max. 3.0 mm |
| Band clipping knive: |
0.4 – 3.0 mm (Max. 3.0*30/1.0*40 mm) |
| Edge material : |
Werkstukhoogte +5 mm (45 mm) |
| Panel thickness: |
8 – 50 mm |
| Panel width: |
When Workpiece thickness 12-22mm 70 mm* |
|
When Workpiece thickness23-40 mm, 120 mm* |
|
*in relation to workpiece length |
| Workpiece width to tools: |
min. 38 mm |
| Edgeband cross dimensions max. |
Bei PVC 135 mm² (max. 6 mm) |
| Roll diameter: |
max. 830 mm |
| Feed Speed: |
8 m/min. |
|
|
| Table height: |
950 mm |
| Air pressure: |
min. 6 bar |
| Machine lenght: |
3.780 mm |
|
|
| Condition: |
Fully functional and optical immaculate condition |
